型号 |
|
1568 |
2068 | |
|
滑台数 |
Number of Tool Slides |
5 |
5 | |
|
支轴数 |
Number of Shafts |
2 |
2 | |
|
**加工直径 |
Max.Processing Diameter |
15MM |
20MM | |
|
**加工长度 |
Max.Turning Length |
30MM |
30MM | |
|
**攻丝直径 |
快削钢 |
Mac.Threading Diameter |
M10P1。0 |
M10P1。0 |
|
快削铁 |
7/16-14 |
7/16-14 | ||
|
主轴回转数 |
Main Spindle Rotation |
2400-8400rpm |
2400-8400rpm | |
|
主轴变速数 |
Main Spindle Speed Cariation |
5 |
5 | |
|
凸轮轴回转数 |
Camshaft Rotation |
1.4-45.7 rpm |
1.4-45.7 rpm | |
|
凸轮轴变速数 |
Camshaft Speed Variation |
15 |
15 | |
|
主动力马达 |
Main Motor |
2HP |
2HP | |
|
地面到主轴中心高度 |
Height From Floor to Main Spindle CAenter |
1100MM |
1100MM | |
|
机械材积 |
Measures(Length,width,height)mm |
1350X650X1550 |
1350X650X1550 | |
|
附送料架 |
With Feeding Support mm |
4350X650X1550 |
4350X650X1550 | |
|
重量（约） |
Weight(about) |
760KG |
770KG | |
