| 主要規格 SPECIFICATI** | ||||
| 滑台數 | Number of Tool slides | 5 | ||
| 支軸數 | Number of Shafts | 3 | ||
| **加工直徑 | Max. Processing Diameter | Φ11 mm | ||
| **加工長度 | Max. Turning Length | 60 mm | ||
| **攻牙徑 | 快削銅 | Max. Threading Diameter | Free Cutting Brass | M6P1.0 |
| 快削鋼 | Free Cutting Steel | M5P1.0 | ||
| 主軸回轉數 | Main Spindle Rotation | 1910～6750 rpm (7 steps) | ||
| 凸輪軸回轉數 | Camshaft Rotation | 0.1～35 rpm Non-step change speed | ||
| 動力 | 主馬達 | POWER | Main Motor | 2 HP(1.5kw) |
| 切削油泵 | Oil Pump | 1/5 HP(0.8kw) | ||
| 地面至主軸中心高度 | Height From Floor to Main Spindle Center | 1150 mm | ||
| 機器尺寸(不含送料架) | Dimensi** (Without Feeding Support) mm | 1800x800x1600 | ||
| 重量(約) | Weight (about) | 880 kgs | ||
