| 規格表 / Specification | |||
| NC控製器 | Fanuc | NC Controller | |
| 加工能力 | **加工直徑 | Φ42mm | Max. Processing Diameter |
| Capacity | **加工長度/夾頭 | 150 mm/ 175mm | Max. Turning Length / Chuck |
| 主軸 Spindle |
主軸鼻端 | A2-5 | Spindle Nose |
| 棒材容徑 | Φ12mm - Φ42mm | ID of Chuck Closing Tube | |
| 主軸轉速 | 170-5,000 rpm | Spindle Speed Range | |
| 刀具係統 Turret & Tooling System |
刀塔形式 | 12角動力刀塔 12-Station Servomotor Turret | Type of Turret |
| 刀具數 | 12 pcs | Tool Holder | |
| 外徑刀杆橫切面尺寸 | 20mm | Tool shank Size | |
| **搪孔刀杆徑 | Φ25mm | Max. Bore Dia. of Tool | |
| X軸、Z軸行程 | X:125mm / Z:255mm | X, Z Axis Slide Travel | |
| 快速移動速度 | 18 m/min | Rapid Traverse Speed | |
| 換刀速度 | 0.18 - 0.23 sec / 1 stn. | Turret Index Time | |
| 動力係統 Motor |
主軸馬達 Cont./50%ED | VAC 5.5KVW | Spindle Motor Cont./50%ED |
| X,Z軸馬達 | VAC 1.6KW | X,Z Axis Motor | |
| 動力刀塔馬達 | VAC 2.2 / 3.7KW | Turret Servo Motor | |
| 油壓馬達 | 2HP | Hydraulic Motor | |
| 切削液馬達 | 1/4HP | Coolant Liquid Motor | |
| 油箱容量 | 100L | Oil-tank Capacity | |
| 體積 (長 x 寬 x 高) | 2,935 x 1,655 x 2,280 mm | Dimension (W x D x H) | |
| 重量 (約) | 2,680 kgs | Weight (approximately) |
| 標準配備/Standard Accessories | ||||
| 標準型刀架 | Standard Tools | 成品補助器 | Part-Catcher Helper | |
| 油壓夾頭用腳踏開關 | Foot Control Switch of Hydrulic Chuck | 成品輸送機 | Finished Parts Conveyor | |
| 特殊配備/Optional Accessories | 鐵屑輸送機 | Chip Conveyor | ||
| 單棒材送料機 | Single Bar Feeder | 全自動穩壓器(20KVA) | Automatic Voltage Regulator(20KVA) | |
| 自動棒材送料機 | Standard Tools | 全自動變壓穩壓兩用裝置 | Automatic Voltage Regulator & Convertor(20KVA) | |
| 油霧回收器 | Coolant Mist Collector | 動力刀座 | Power Tool Seat | |
| 深孔鑽高壓冷卻裝置 | High-pressure Coolant System | 底盤 | Bottom Pan | |
