| 規格表 / Specification | ||||
| NC控製器 | Fanuc | Mitsubishi | NC Controller | |
| 加工能力 | **加工直徑 | Φ42mm | Max. Processing Diameter | |
| Capacity | **加工長度/夾頭 | 150 mm/ 175mm | Max. Turning Length / Chuck | |
| 主軸 Spindle |
主軸鼻端 | A2-5 | Spindle Nose | |
| 棒材容徑 | Φ12mm - Φ42mm | ID of Chuck Closing Tube | ||
| 主軸轉速 | 170-6,000 rpm | Spindle Speed Range | ||
| 主軸馬達 Cont./50%ED | VAC 5.5 / 7.5kw | Spindle Motor Cont./50%ED | ||
| 刀塔係統 Turret & Tooling System |
刀塔形式 | 八角刀塔 8-Station Turret | Type of Turret | |
| 外徑刀杆橫切面尺寸 | 20mm | Tool shank Size | ||
| **搪孔刀杆徑 | Φ25mm | Max. Bore Dia. of Tool | ||
| X軸、Z軸行程 | X:100mm / Z:185mm | X, Z Axis Slide Travel | ||
| 快速移動速度 | 12 m/min | Rapid Traverse Speed | ||
| 換刀速度 | 0.1 - 0.2 sec / 1 stn. | Turret Index Time | ||
| 體積 (長 x 寬 x 高) | 2,060 x 1,435 x 1,640 mm | Dimension (W x D x H) | ||
| 重量 (約) | 2,150 kgs | Weight (approximately | ||
