| 主要規格 SPECIFICATI** | W-1568 | W-2068 | |||
| 滑台數 | Number of Tool slides | 5 | 5 | ||
| 支軸數 | Number of Shafts | 2 | 2 | ||
| **加工直徑 | Max. Processing Diameter | Φ15 mm | Φ20 mm | ||
| **加工長度 | Max. Turning Length | 30 mm | 30 mm | ||
| **攻牙徑 | 快削銅 | Max. Threading Diameter | Free Cutting Brass | M10P1.0 7/16"-14牙 |
M10P1.0 7/16"-14牙 |
| 快削鋼 | Free Cutting Steel | ||||
| 主軸回轉數 | Main Spindle Rotation | 2,400～8,400 rpm | 2,400～8,400 rpm | ||
| 主軸變速數 | Main Spindle Speed Variation | 5 | 5 | ||
| 凸輪軸回轉數 | Camshaft Rotation | 1.4～45.7 rpm | 1.4～45.7 rpm | ||
| 凸輪軸變速數 | Camshaft Speed Variation | 15 | 15 | ||
| 主動力馬達 | Main Motor | 2 HP | 2 HP | ||
| 地面至主軸中心高度 | Height From Floor to Main Spindle Center | 1100 mm | 1100 mm | ||
| 機械材積 | 1350 x 650 x 1550 | 1350 x 650 x 1550 | |||
| 附送料架 | Dimensi** (Without Feeding Support) mm | 4350 x 650 x 1550 | 4350 x 650 x 1550 | ||
| 重量(約) | Weight (about) | 760 kgs | 770 kgs | ||
| 標準附件 STANDARD ACCESSORIES | ||
| 送料裝置 | Feeding Support | 1 kit |
| 攻牙安全裝置 | Tapping Safety Device | 1 kit |
| 切削冷卻裝置 | Cooling Device for Cutting | 1 kit |
| 調整工具 | Adjust Tools | 1 set |
| 筒夾頭 | Collet Chuck | 1 pic |
